Rigol DS1054Z Oscilloscope

The Rigol DS1000Z Series is a high-performance, cost-effective range of digital oscilloscopes designed for a wide range of applications, including electronic design, embedded system development, education, and industrial maintenance.

Powered by Rigol’s UltraVision technology, these oscilloscopes offer deep memory, high waveform capture rates, and advanced analysis capabilities—ideal for professionals and educators alike.

Key Features

• Bandwidth Options: Available in 50 MHz, 70 MHz, and 100 MHz models to suit diverse testing needs.

• 4 Analog Channels: All models come standard with four channels, enabling simultaneous multi-signal observation.

• High Sampling Rate: Up to 1 GSa/s real-time sampling, ensuring accurate signal capture and display.

• Deep Memory: Standard 12 Mpts memory, expandable up to 24 Mpts, ideal for long-duration waveform acquisition.

• Waveform Capture Rate: Up to 30,000 wfms/s, greatly improving the ability to capture transient or elusive events.

• Mixed-Signal Capability: The “Plus” models can be upgraded with the RPL1116 logic probe to become 16-channel Mixed Signal Oscilloscopes (MSO).

• Built-in Waveform Generator: Select models (e.g., DS1074Z-S Plus and DS1104Z-S Plus) include a dual-channel 25 MHz arbitrary waveform generator, providing a complete test solution in one instrument.
