Siglent SHS810X Handheld Oscilloscope

The Siglent SHS800X Series is a line of economical, rugged, and portable handheld digital oscilloscopes. Designed for safe and convenient operation in the field, its most critical feature is the inclusion of fully isolated input channels, compliant with CAT II 1000V and CAT III 600V safety standards for secure floating signal measurements. This 2-in-1 instrument combines the power of a digital oscilloscope, with up to 200 MHz bandwidth and a 1 GSa/s sample rate, and the utility of a 6000-count digital multimeter. Housed in an IP51-rated enclosure with a long-life battery, the SHS800X series is an excellent and affordable tool for industrial maintenance, automotive diagnostics, and general field testing.

Key Features

• Isolated Input Channels: Two fully isolated oscilloscope channels provide a high degree of safety, allowing users to confidently perform floating measurements in power electronics and other circuits without a common ground.
• High Safety Compliance: The oscilloscope inputs are safety-rated for CAT II 1000V and CAT III 600V, making the instrument suitable for measurements in demanding industrial environments.
• 2-in-1 Instrument Versatility: Seamlessly switch between a full-featured oscilloscope and a 6000-count True RMS digital multimeter. The multimeter function measures DC/AC Voltage, DC/AC Current, Resistance, Capacitance, Diodes, and Continuity.
• Comprehensive Data Logger: The recorder function can capture waveforms into a 7Mpts internal memory or log data for extended periods to a connected USB device. A Trend Plot feature visually displays measurement changes over time.
• Solid Oscilloscope Performance: With up to 200 MHz bandwidth, a 1 GSa/s single-channel sample rate, and up to 12 Mpts of memory depth, the SHS800X captures complex waveforms with excellent detail and precision.
• Designed for Fieldwork: Features a robust IP51-rated casing for dust and water protection, a rechargeable battery for up to 4 hours of operation, and a bright 5.6-inch TFT-LCD display for easy reading in various conditions.
• Full Suite of Measurement Tools: Comes equipped with 32 automatic measurements, comprehensive math functions including FFT, and USB connectivity for easy data storage and PC analysis.
