Tonghui TH8405 DC Electronic Load

The TH8400 Series offers a cost-effective yet high-performance lineup of programmable DC electronic loads, featuring power ratings from 175 W to 2000 W, voltage capabilities of 150 V or 500 V, and current up to 240 A. With a dynamic bandwidth reaching 25 kHz and a high 500 kHz sampling rate, this series helps engineers test DC power supplies, batteries, solar arrays, EV components, and electronic components with precision and confidence.

Key Features

• Wide Operating Range: Tailor the load to your specific needs with power ratings from 175W to 2000W, input voltage options of 150V and 500V, and current capabilities ranging from 15A to 240A.
• High-Speed Dynamic Testing: Featuring a dynamic test frequency of up to 25kHz and a rapid measurement sampling speed of up to 500kHz, the TH8400 is perfectly equipped to capture transient characteristics and test the dynamic response of modern power supplies.
• Exceptional Measurement Accuracy: Achieve reliable and repeatable results with high-resolution measurements of 1mV and 0.1mA. The low ripple and noise floor ensure that the measurements you take are true to your device’s performance.
• Advanced Waveform Analysis: Go beyond standard measurements with integrated features for ripple and peak value analysis. The TH8400 can measure and display voltage/current ripple (Vp-p/Ip-p) and peak values, providing critical insight into the stability and quality of your power source.
• Unique On-Screen Waveform Display: A standout feature of the series is its ability to display voltage and current waveforms directly on the VFD screen. This allows for real-time analysis and troubleshooting without the need for an external oscilloscope, saving time and bench space.
• Comprehensive Operating Modes: With 11 distinct operating and measurement functions, the TH8400 series offers ultimate flexibility. Standard modes include Constant Current (CC), Constant Voltage (CV), Constant Resistance (CR), and Constant Power (CP).

Applications

The robust design and versatile feature set of the TH8400 Series make it an essential tool across various industries and applications:

• Power Supply Manufacturing: Testing of AC/DC power supplies, DC/DC converters, and LED drivers.
• Battery Technology: Battery discharge testing, capacity analysis, and internal resistance measurement.
• Automotive and Aerospace: Component testing and power system validation.
• Research & Development: Prototyping, characterization, and validation of new power electronic designs.
• Education: Providing students with hands-on experience with fundamental power electronics principles.
