The UPO1000X Series represents UNI-T’s cutting-edge innovation in test instrumentation, featuring breakthrough digital 3D processing technology for superior waveform visualization and analysis. With 100MHz/200MHz bandwidth options and 2GSa/s real-time sampling, these oscilloscopes deliver deep memory, ultra-fast capture rates, and advanced decoding for professional engineers across industries.
Key Features & Innovations
1. Unmatched Waveform Capture & Processing
- 500,000 wfms/s max. waveform capture rate (Fast Acquire mode)
- 150,000 wfms/s in normal sampling mode
- 56Mpts deep memory with full-memory hardware decoding (<300ms latency)
- 256-level grayscale display for enhanced signal detail
2. Advanced Analysis & Decoding
- Real-time waveform recording & playback (up to 120,000 frames)
- 1M-point FFT with independent spectrum view (4 traces + peak detection)
- Hardware-based protocol decoding: RS232/UART, I²C, SPI
- Auto-parameter measurement with snapshot & threshold settings
3. Smart User Experience
- Web Control: Remote access via LAN/WAN + online help
- Flat UI design: One-touch home menu, single-layer navigation
- Dedicated DVM module: 4-digit AC/DC RMS measurement with alarm
- New functions:
- 500μV/div sensitivity | Brightness adjustment | Single-shot DSO mode
4. Versatile Connectivity
- USB, LAN, HDMI
- Cross-platform control (PC/mobile)
| MODEL | BANDWIDTH | ANALOG CHANNELS |
REAL-TIME SAMPLE RATE |
MAX.MEMORY DEPTH |
WAVEFORM CAPTURE RATE |
| UPO1054 | 50MHz | 4 | 2GSa/s | 56Mpts | 500,000wfms/s |
| UPO1104 | 100MHz | 4 | 2GSa/s | 56Mpts | 500,000wfms/s |
| UPO1204 | 200MHz | 4 | 2GSa/s | 56Mpts | 500,000wfms/s |
