UNI-T UT673A Battery Tester

Features

• Versatile Testing: Capable of conducting 12V cranking lead acid battery tests, as well as 12/24V charging or cranking system tests. This wide – range testing ability makes them adaptable to different vehicle electrical systems.
• Comprehensive Data Display: Can display crucial battery parameters such as capacity, voltage, resistance, and life. This provides users with a complete understanding of the battery’s condition at a glance.
• Advanced Testing Method: Utilizes a four – terminal Kelvin test, which enhances the accuracy of resistance measurement by minimizing the impact of lead resistance.
• Multiple Battery Standards: Supports 10 types of battery standards, including CCA (40 – 2000), BCI (40 – 2000), CA (40 – 2000), MCA (40 – 2000), JIS (26A17 – 245H52), DIN (40 – 1400), IEC (40 – 1400), EN (40 – 2000), SAE (40 – 2000), and AH (3 – 250AH). This allows for compatibility with various battery models and specifications.
• User – Friendly Design: Offers a Chinese/English language option, making it accessible to a wide range of users. Additionally, the testers can perform tests without the need to disassemble the battery, which is convenient and time – saving.
• Result Indication: The UT673A features LED color indication for test results, enabling quick and intuitive assessment of the battery’s status.
• Data Transfer and Reporting: The UT675A comes with USB communication and a built – in printer. This allows for easy data transfer to other devices and on – line, real – time printing of test reports, facilitating record – keeping and analysis.
• Protection Functions: Both models are equipped with over – voltage protection, reverse – connection protection, and a prompt for poor contact. These features safeguard the tester and the battery during the testing process, ensuring safe and reliable operation.

Specifications

• Certificates: CE, FCC, RoHS certified, guaranteeing compliance with international standards.
• Voltage Ranges: Suitable for 12V battery tests within the range of 7 – 16V DC, and 12V/24V cranking and charging system tests in the 7 – 30V DC range.
• Battery Types: Compatible with ordinary lead acid batteries, AGM flat plate batteries, AGM spiral batteries, GEL batteries, and EFB batteries.
• General Characteristics: Powered by an external source, with a 128*64 black – and – white lattice display. The UT673A weighs 264g and has dimensions of 76mm x 22mm x 142mm, while the UT675A weighs 413g and measures 95mm x 47mm x 183mm.
