The UTD1000L Series Digital Oscilloscopes from Uni-Trend offer a cost-effective solution for basic to intermediate signal measurement tasks. Designed for engineers, technicians, and students, these oscilloscopes provide essential features in a compact and user-friendly package. With bandwidth options up to 100 MHz, the UTD1000L Series is ideal for education, hobbyist projects, and general electronics troubleshooting.
Key Features:
-
Bandwidth Options (50/70/100 MHz) – Suitable for a wide range of signal analysis needs.
-
7-inch TFT-LCD Display (800×480 resolution) – Clear and intuitive waveform visualization.
-
Real-time Sampling Rate up to 1 GSa/s – Ensures accurate capture of fast signal transitions.
-
Memory Depth up to 28 Mpts – Allows for detailed waveform recording and analysis.
-
Multiple Trigger Modes (Edge, Pulse, Video, Slope, etc.) – Flexible signal capture for different applications.
-
Built-in Dual-channel DMM (Optional) – Provides voltage, resistance, and continuity measurements (select models).
-
USB Host & Device Support – Enables data storage, printing, and PC connectivity.
-
Lightweight & Portable Design – Easy to carry for fieldwork or lab use.
Applications:
-
Educational labs & training
-
Basic electronics debugging
-
Power supply & circuit testing
-
DIY projects & hobbyist use
| MODEL | BANDWIDTH | ANALOG CHANNELS | REAL-TIME SAMPLE RATE | MAX.MEMORY DEPTH |
| UTD1025DL | 25 MHz | 2 | 250 Msa/s | 12 kpts |
| UTD1050CL | 50 MHz | 1 | 200 Msa/s | 12 kpts |
| UTD1025CL | 25 MHz | 1 | 200 Msa/s | 12 kpts |
| UTD1050DL | 50 MHz | 2 | 250 Msa/s | 12 kpts |
